AM-Series
Sunnex AM-Series Anti-Vibration Mounts are best suited for those applications where vibration attenuation and chemical resistance is of primary concern.
The entire shape and form of the stainless steel and zinc plated machine mounts excludes pockets or recesses where dirt or moisture can collect helping to prevent corrosion or bacterial growth. This makes the AM-Series ideal for applications that require constant cleaning.
The bolt through connection of the base unit and the bolt provide a solid connection while providing the advantage of a 7.5 degree swivel.
M-Series
The M-Series OSM vibration mount is designed for use on machinery that does not require fastening to the floor. It has been designed with the aid of FEM analysis, which prevents fatigue from fast working cycle times and strong lateral forces in heavy machinery.
Replacing the M-series mount is easy - simply unscrew and slide the mount under the machine. The reinforced leveling bolt support cup distributes machine loads to the support points within the mount. The leveling element provides direct and reliable machine mounting to suit most installation needs.
Vertical as well as horizontal forces are dampened out by the integral nitrile pad, which also provides chemical resistance to most fluids.
MHD-Series
The MHD leveling element is ideal for machines exerting significant vertical and horizontal forces, where a secure, high-precision connection between the bedding element and machine is required. The unique design absorbs impulses and shock in high-speed machinery, where damping is critical.
The Sunnex MHD consists of the following components: impact housing, pressure plate, pressure cylinder and integrated adjustable screw with nut and washer. This patented design is the key to providing 1/100mm leveling accuracy over the entire 30mm range. An integral locking device prevents the MHD from coming apart during installation or relocation of the machine. It maintains excellent horizontal dynamic stability and features a specially designed damping pad that effectively isolates supported machinery.
SP-Series
Sunnex SP machine vibration pads are used in many areas of industry to insulate machinery against the adverse effects of impact, vibration, and structure-borne noise, and also to prevent slipping.
There are 5 types of SP machine vibration pads to choose from, each with its own specific hardness, natural frequency, and load-bearing characteristics.
SP machine vibration pads are resistant to all types of grease, acid, oil, and cooling emulsion normally encountered in manufacturing environments. The pad also provides an excellent tolerance to a wide range of temperature variations. All SP machine vibration pads are made of special nitrile rubber, a material containing no PVC or silicon.
Vibrostop Rubber Vibration Isolators
Vibrostop innovative rubber mounts, are coupled with aluminum or steel parts to provide optimal vibration isolation in a broad range of applications, from HVAC units to submarines. Sunnex and Vibrostop are part of Amplex, a privately owned Swedish corporate group that acquires, owns and develops technology-based businesses in selected niches. Sunnex USA is the official distributor of VIBROSTOP products in North America.
Vibrostop Spring Mounts
Vibrostop unique Spring mounts dampers incorporate steel springs with intrinsic low frequency that provides the highest level of vibration isolation in HVAC/R systems. Sunnex and Vibrostop are part of Amplex, a privately owned Swedish corporate group that acquires, owns and develops technology-based businesses in selected niches. Sunnex USA is the official distributor of VIBROSTOP products in North America.
Vibrostop Wire Rope Isolators
Vibrostop's unique Shock and vibration isolation components with elastic element made of coiled stainless steel wire rope resists to atmospheric agents for long lasting performance. This makes them and ideal solution for isolating critical components during transportation, military applications and many others. Sunnex and Vibrostop are part of Amplex, a privately owned Swedish corporate group that acquires, owns and develops technology-based businesses in selected niches. Sunnex USA is the official distributor of VIBROSTOP products in North America.
WM-Series
The Sunnex WM wedge style series of leveling mounts are designed for applications requiring the highest load capacities, as well as high-precision leveling adjustment. The WM series combines minimal height profile with passive vibration dampening.
The WM is most widely used in its standard configuration of free standing connection, however for those equipment types with large horizontal forces. Sunnex WM leveling mounts are available in both a bolt on and a bolt through design variation.
